Product Summary
The CM100BU-12H is an IGBT module. It is designed for use in switching applications. The CM100BU-12H consists of four IGBTs in an H-Bridge configuration, with each transistor having a reverse-connected superfast recovery free-wheel diode. All components and interconnects are isolated from the heat sinking baseplate, offering simplified system assembly and thermal management. The applications of the CM100BU-12H are AC Motor Control, Motion/Servo Control, UPS, Welding Power Supplies.
Parametrics
CM100BU-12H absolute maximum ratings: (1)Junction Temperature:-40 to 150℃; (2)Storage Temperature:-40 to 125℃; (3)Collector-Emitter Voltage (G-E SHORT):600 Volts; (4)Gate-Emitter Voltage (C-E SHORT):±20 Volts; (5)Collector Current (Tc = 25℃):100 Amperes; (6)Peak Collector Current:200 Amperes; (7)Emitter Current:100 Amperes; (8)Peak Emitter Current:200 Amperes; (9)Maximum Collector Dissipation:400 Watts; (10)Isolation Voltage (Main Terminal to Baseplate, AC 1 min.):2500 Vrms.
Features
CM100BU-12H features: (1)Low Drive Power; (2)Low VCE(sat); (3)Discrete Super-Fast Recovery; (4)Free-Wheel Diode; (5)High Frequency Operation; (6)Isolated Baseplate for Easy Heat Sinking.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 CM100BU-12H |
|
IGBT MOD H-BRDG 600V 100A U SER |
Data Sheet |
|
|
||||||
