Product Summary

The 2DI150MA-050 is a power transistor module. The applications of it include power switching, A.C motor controls, D.C motor controls, uninterruptible power supply.

Parametrics

2DI150MA-050 absolute maximum ratings: (1)VCBO:600V; (2)VCEO:600V; (3)VEBO:10V; (4)IC:150A; (5)ICP:300A; (6)-IC:150A; (7)IB:9A; (8)IBP:18A; (9)PC:one transistor:690W, two transistors:1380W; (10)Tj:+150℃; (11)Tstg:-40℃ to +125℃; (12)m:450g; (13)Viso:2500V;(14)VCEO(SUS):450V.

Features

2DI150MA-050 features: (1)high DC current gain; (2)including free wheeling diode; (3)high speed switching; (4)insulated type.

Diagrams

2DI150MA-050 circuit
