LM239

Low Power, Low Offset Voltage, Quad Comparator, SOP14, 2 to 36 VDC, 1050 mW

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.30~0.80 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.30~0.80

PartNumber:: LM239

Brand:: National Semiconductor - NS | Pack: SOP | D/C: 11+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Alex's store

(Hong Kong)

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-14

From Other Seller

Part Number:LM239
US $0.30 - 0.80
ECA1HHG4R7

US $10.00 - 10.00 / Piece
(0) Remove
ECA1HHG100

US $10.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The LM239 is a Low Power Low Offset Voltage Quad Comparator. The LM239 consists of four independent precision voltage comparators with an offset voltage specification as low as 2 mV max for all four comparators. The LM239 is designed specifically to operate from a single power supply over a wide range of voltages. Operation from split power supplies is also possible and the low power supply current drain is independent of the magnitude of the power supply voltage. The LM239 also has a unique characteristic in that the input common-mode voltage range includes ground, even though operated from a single power supply voltage.

Parametrics

LM239 absolute maximum ratings: (1)Supply Voltage, V+: 36 VDC or ±18 VDC; (2)Differential Input Voltage: 36 VDC; (3)Input Voltage: -0.3 VDC to +36 VDC; (4)Input Current (VIN<-0.3 VDC): 50 mA ; (5)Power Dissipation: 1050 mW; (6)Storage Temperature Range: -65 to +150℃; (7)Lead Temperature (Soldering, 10 seconds): 260℃; (8)Operating Temperature Range: 0 to +70℃; (9)Soldering Information: 260℃; (10)ESD rating: 600V.

Features

LM239 features: (1)Wide supply voltage range; (2)Very low supply current drain (0.8 mA) — independent of supply voltage; (3)Low input biasing current: 25 nA; (4)Low input offset current: ±5nA; (5)Offset voltage: ±3mV; (6)Input common-mode voltage range includes GND; (7)Differential input voltage range equal to the power supply voltage; (8)Low output saturation voltage: 250 mV at 4 mA; (9)Output voltage compatible with TTL, DTL, ECL, MOS and CMOS logic systems.
