Product Summary

The PWR70 is a dual-output DC/DC converter designed for general purpose power conversion applications where high efficiency is more important than load regulation. The PWR70 provides a plus and minus output voltage approximately equal to the input voltage magnitude. It operates over an input voltage range of 10VDC to 18VDC. Isolation voltage is a minimum of 2000VDC. The PWR70 is tested in compliance with UL544, VDE750, and CSA C22.2 dielectric withstand voltage requirements.

Parametrics

PWR70 absolute maximum ratings: (1)Input Voltage: 18VDC; (2)Output Current: ±150mA; (3)Output Short-Circuit Duration: Continuous.

Features

PWR70 features: (1)tested in compliance with ul544; (2)output power to 3w; (3)high isolation voltage: 2000vdc; (4)six-sided shielding; (5)input and output filtering.

Diagrams

PWR70 view

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
PWR70
PWR70
Murata Power Solutions
DC/DC Converters 3W 15V to +/-15V
Data Sheet
Negotiable
PWR7000CC
PWR7000CC
Murata Power Solutions
DC/DC Converters PWR7000CC
Data Sheet
Negotiable
PWR7005A
PWR7005A
Murata Power Solutions
DC/DC Converters 5W REG DC/DC CONV
Data Sheet
Negotiable
PWR7005AC
PWR7005AC
Murata Power Solutions
DC/DC Converters 5V+/-15Vout +/-167mA 5W REGULATED
Data Sheet
Negotiable
PWR70C
PWR70C
Murata Power Solutions
DC/DC Converters 15V+/-15Vout +/-15mA 3W High Iso Unreg
Data Sheet
