Product Summary
The EC167D is a kind of oscillator.
Parametrics
EC167D absolute maximum ratings: (1)Frequency Range (MHz): 1.000MHz to 20.000MHz; (2)Operating Temperature Range: Per Table 1; (3)Storage Temperature Range: -55 to 125℃; (4)Supply Voltage (VDD): 5.0VDC ±10%; (5)Input Current, 1.000MHz to 20.000MHz: 15 mA maximum; (6)Input Current, 20.000MHz to 46.000MHz: 40 mA maximum.
Features
EC167D features: (1)RoHS Compliant (Pb-free); (2)HCMOS/TTL output; (3)5.0V supply voltage; (4)14 pin DIP package; (5)Stability to ±5ppm; (6)Custom lead length, gull wing options available.
Diagrams
 |
